    Y Series Slips Type Elevators

    The slip type elevator is an indispensable tool in holding and hoisting drilling pipes, casing and tubing in the oil drilling and well tripping operation. It’s especially suitable for the hoisting of integrated tubing sub, integral joint casing and electric submersible pump column.

    Y Series Slips Type Elevators

    Model

    Size

    Rated Cap.

    mm(in)

    kN

    Short Tons

    HYT

    60.3-88.9 (23/8-31/2)

    1350

    150

    YT

    33.4-88.9 (1.315-31/2)

    675

    75

    MYT

    33.4-73 (1.315-27/8)

    360

    40

    LYT

    26.7-52.4 (1.05-11/16)

    180

    20

    HYC

    88.9-139.7 (31/2-75/8)

    1800

    200

    MYC

    88.9-117.8 (31/2-7)

    1125

    125

    YC

    88.9-117.8 (31/2-7)

    675

    75
